| Series |
680 |
| Status |
Active |
| Certifications |
RoHS |
| Features |
High Intensity |
| Mounting Hole Size |
0.413" (10.5mm) |
| Output |
Single Color |
| Emitted Color |
Red |
| LED Position |
Internal |
| Lens Color |
Tinted, Diffused |
| Voltage |
12 VDC |
| Resistor |
Internal Resistor Included |
| Mounting Method |
Nut/Washer |
| Max Panel Thickness |
.236" (6.0mm) |
| Mounting Torque |
0.217 |
| Mounting Torque Unit of Measure |
lb-ft |
| Typical Current (mA) |
15 |
| Typical Intensity (mcd) |
1530 |
| Termination |
Solder Terminals |
| Termination Finish |
Nickel Plated |
| Housing Material |
Polycarbonate |
| Lock Washer |
White Nickel |
| Nut |
White Nickel |
| Operating Temperature |
-20°C to +75°C (-4°F to +167°F) |
| Storage Temperature |
-40°C to +100°C (-40F to +212°F) |
